Cheap SLB-10 electric welding elevating positioner for sale
The machine adopts the working form of the L-shaped lifting and shifting machine, and uses the end face of the workpiece as the mounting positioning surface to complete the loading of the workpiece. Through the electric turning of the workbench, the workpiece is placed in the most ideal position for welding work, which can meet the multi-angle multi-position welding requirements of the workpiece, reduce labor intensity and improve labor productivity.
According to the structural characteristics of the workpiece, the workpiece is welded at various angles by lifting, turning and turning the table.
Through the lifting operation of the table top of the positioner, it is possible to adapt to the welding work of workpieces of different lengths and inverted diameters within a certain range, and it has certain versatility and can meet the needs of different production requirements.
Main technical parameter
| SN. | Item | Parameters |
| 1 | Max. Loading capacity | 1000kg |
| 2 | Table tilting speed | 0.8rpm |
| 3 | Table tilting center height | 700mm～1700mm |
| 4 | Table tilting angle | N×360° |
| 5 | Table lifting speed | 500mm/min |
| 6 | Table rotation speed | 0.05~0.5rpm |
| 7 | Workpiece Max. Rotation dia. | Φ3000mm |
| 8 | Worktable dia. | Φ1000mm(Extend arm Φ1900mm) |
| 9 | Rated tilting torque | 5000Nm |
| 10 | Worktable lifting stroke | 1000mm |
| 11 | Worktable rotation torque | 3000Nm |
| 12 | Conduction current | 1000A |
What Ronniewell can do for Ronniewell customers:
1. Give you high quality products.
2. Give you five-star price.
3. Give you suitable recommendation.
4. Give you good after-service.
5. Give you professional technical guide.
Customization - Can your machine or other products be customized?
Ronniewell: Sure. As a professional manufacturer, we have our own engineer team, who is good at design, develop & build special solution catering for your individual requirement.
Transportation-What about the transportation?
Ronniewell: Seaway is the most common transportation way for oversea trading. Depends on your location, combined transport by rail and sea is also an option. Certainly railway transportation is also acceptable if it is the most suitable approach.
After sale service - What about the after-sale service?
Ronniewell: We provide 12month guaranty period for the whole machine quality. During this time, any issue proved because of the machine flaw itself,we would take the whole responsibility of it. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine. Engineer service on user premises is also available for necessary.
